Hardware Specifications
|
CPU
|
CPU Model
|
Intel Celeron J3355
|
|
CPU Quantity
|
1
|
|
CPU Core
|
2
|
|
CPU Architecture
|
64-bit
|
|
CPU Frequency
|
2.0 (base) / 2.5 (turbo) GHz
|
|
Hardware Encryption Engine
|
|
Memory
|
System Memory
|
2 GB DDR3 non-ECC SODIMM
|
|
Memory Module Pre-installed
|
2 GB (2 GB x 1)
|
|
Total Memory Slots
|
2
|
|
Maximum Memory Capacity
|
6 GB (2 GB + 4 GB)
|
|
Notes
|
-
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
-
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
|
Storage
|
Drive Bays
|
6
|
|
Drive Type (See all supported drives)
|
-
2.5" SATA HDD
-
2.5" SATA SSD
|
|
Hot Swappable Drive*
|
|
External Ports
|
RJ-45 1GbE LAN Port
|
2
|
|
USB 3.2 Gen 1 Port
|
2
|
Appearance
|
Size (Height x Width x Depth)
|
121 mm x 151 mm x 175 mm
|
|
Weight
|
1.4 kg
|
Others
|
System Fan
|
80 mm x 80 mm x 1 pcs
|
|
Fan Speed Mode
|
-
Full-Speed Mode
-
Cool Mode
-
Quiet Mode
|
|
Easy Replacement System Fan
|
|
|
Brightness Adjustable Front LED Indicators
|
|
|
Power Recovery
|
|
|
Noise Level*
|
20.5 dB(A)
|
|
Scheduled Power On / Off
|
|
|
Wake on LAN / WAN
|
|
|
Power Supply Unit / Adapter
|
65 watts
|
|
AC Input Power Voltage
|
100V to 240V AC
|
|
Power Frequency
|
50/60 Hz, Single Phase
|
|
Power Consumption*
|
34.88 watts (Access)
7.59 watts (HDD Hibernation)
|
|
British Thermal Unit
|
119.1 BTU/hr (Access)
25.92 BTU/hr (HDD Hibernation)
|
|
Notes
|
-
Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
-
Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 17.2 dB(A); Temperature: 23.6˚C; Humidity: 58.2%.
|
Temperature
|
Operating Temperature
|
5°C to 40°C (40°F to 104°F)
|
|
Storage Temperature
|
-20°C to 60°C (-5°F to 140°F)
|
|
Operating Humidity
|
8% to 80% RH
|
|
Storage Humidity
|
5% to 95% RH
|
Certification
|
|
Warranty
|
2-year hardware warranty, extendable to 4 years with Extended Warranty Plus
|
|
Notes
|
-
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
-
Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions. (Learn more)
|
Environment
|
RoHS Compliant
|
Packaging Content
|
-
Main Unit X 1
-
AC Power Adapter X 1
-
AC Power Cord X 1
-
RJ-45 LAN Cable X 2
-
Quick Installation Guide X 1
|
Optional Accessories
|
|
